High Temperature Pressure Sensor

AV40HT


Benefits

» One piece design
» No welded, No oil-filling, No O-ring
» Excellent accuracy
» Excellent long-term stability

Applications

» Semiconductor Manufacturing
» Power Generation
» High Pressure Steam
» Chemical Reactor
» Oil & Gas
» Down Holes

Overview

AV40HT is designed to measure pressure measurements under high environment and media temperatures. The Hastelloy C276 wetted parts offer excellent media compatibility with wide range of liquids and gases. Inorganic bonding of the sensing element offers high stability over along periods of time.

Performance @ 25℃ (77℉)

Accuracy* <±0.1% BFSL*
Stability(1 year) <±0.1% FS, typ.
Pressure Range 0-5 to 20,000PSI
Proof Pressure 2X Rated Pressure, standard**
Burst Pressure 5X or, 50,000PSI, whichever is less
Pressure Cycles 100 million
Output 4-20mA 0-5V 0-10V
Excitation 10-28VDC 15-30VDC
Zero Offset <±0.5% FS
Span <±0.5% FS
* Accuracy includes non-linearity, hysteresis & non-repeatability
** For higher proof pressures, contact factory

Environmental Data

Temperature
Operating -40 to 85℃ (-40 to 185℉)
Storage -50 to 125℃ (-58 to 250℉)
Thermal Limits
Compensated Range 0 to 70℃
TC Zero <±0.5% FS
TC Span <±0.5% FS
Other
Shock 100G, 11msec, 1/2 sine
Vibration 10G peak, 20 to 2000hz
EMI/RFI Protection Yes
Rating IP66

Physical Description

Wetted Material 316L, 17-4PH, 718 Inconel
Weight 60g
Electrical Connection Bendix, Din43650, Cable
Reverse Polarity Protection Yes

MODEL NUMBER CONFIGURATION

Not all configurations are available. Our sales team can recommend the closest available configuration based on your requirements. Contact AVERY INSTRUMENT LTD. for configurations not shown.

Contact us

Ordering Method
For Example:-

AV40HTP000SVH5B000

ORDERING INFORMATION

Click the button      and find the AVERY Model number
Ordering Information for AV40HT

DIMENSIONAL DATA


DOWNLOAD DATASHEET


Warranty

🔮 Workmanship - Avery Instrument Limited (AVERY) pressure sensors have a limited one-year warranty to the original purchaser. AVERY will replace or repair, free of charge, any defective sensor. This warranty does not apply to any units that have been modified; misused, neglected or installed where the application exceeds published ratings; the label getting lost, broken,or unrecognizable when return.
Installation/Applications - The purchaser is responsible for media compatibility, functional adequacy, and correct installation of the sensor.
