Pressure Transmitter

AV310

Benefits

» Compact structure
» Digital circuit processing
» Strong anti-interference and excellent long-term stability
» Small diameter, small size, easy to install and use
» Available for measurement of absolute pressure, gauge pressure and sealed gauge pressure
» Multiple electrical connection options
» SS316L Diaphragm
» Suitable for mass production

Applications

» Air compressor
» Hydraulic and pneumatic equipment
» Refrigeration
» Pipeline system
» High Volume

Overview

AV310 pressure transmitter is specially designed for small and medium-sized equipment applications such as booster pump, air compressor and pipeline hydraulic system. It is also applicable to a wide range of industrial applications in a variety of structures, outputs and pressure connections, which meets most application requirementsIt has the compact structure which is especially suitable for the installation in the small spaces.

Performance @ 25℃ (77℉)

Accuracy*	±0.5%FS(typ.); ±1%FS(max.)
Response Time	<90ms
Service Life	≥10x10⁶pressure cycles
Pressure Range	0 ~ 35kPa ...50Bar
Pressure Type	Gauge, Sealed, Absolute
Supply & Output	0-5V	4-20mA	0.5-4.5V Ratiometric
Hysteresis & repeatability	≤ ±0.1%FS
Insulation resistance	≥100MΩ/500VDC (200MΩ/250VDC)

Environmental Data

Temperature
Temperature Drift	≤±1.5%FS(-20℃ ~ 85℃)
Storage	-40℃ ~ 120℃
Thermal Limits
Ambient temp.	-20℃ ~ 80℃
Medium temp.	-30℃ ~ 105℃
Other
IP rating	IP65
Shock	200g/1ms; IEC 60068-2-27 Free fall: 1m; IEC 60068-2-32
Vibration	Sine curve: 20g, 25Hz ~ 2kHz; IEC 60068-2-6 Random: 7.5grms, 5Hz~1kHz; IEC 60068-2-64

Physical Description

Wetted Material	ASTM S31603 (AISI316L)
Body Material	Housing: ASTM S30400 (AISI304)
Electrical Connection	PA66
Weight	120±5g (Cable outlet)
Hexahedral size	HEX22
Withstand voltage	1800VAC 1min

MODEL NUMBER CONFIGURATION

Not all configurations are available. Our sales team can recommend the closest available configuration based on your requirements. Contact AVERY INSTRUMENT LTD. for configurations not shown.

Ordering Method
For Example:-

AV310A000ARL4C007

ORDERING INFORMATION

Click the button➠ and find the AVERY Model number

DIMENSIONAL DATA

DOWNLOAD DATASHEET

Warranty

🔮 Workmanship - Avery Instrument Limited (AVERY) pressure sensors have a limited one-year warranty to the original purchaser. AVERY will replace or repair, free of charge, any defective sensor. This warranty does not apply to any units that have been modified; misused, neglected or installed where the application exceeds published ratings; the label getting lost, broken,or unrecognizable when return.
Installation/Applications - The purchaser is responsible for media compatibility, functional adequacy, and correct installation of the sensor.
