Stainless Steel Media Isolated Industrial Pressure Sensor and Transmitter

AV400

Benefits

» No welds, no internal O-rings, no fluid fill
» Rugged Design organics exposed to the pressure media
» Features digital compensation
» Temperature correction for high accuracy and stability

Applications

» OEM machinery
» Process control
» Industrial Automation
» Plastic molding machines
» Alloy injection molding machines
» Hydraulic, etc.

Overview

AV400 Pressure Sensor is design for industrial and offroad applications. It employs p-n junction free MEMS piezo resistive technology that is inorganically bonded for media isolation. Because of one-piece stainless steel structure, AV400 provides reliable operation in harsh environment. It is well suited for OEM machinery, process control, automation, plastic and alloy injection molding machines, hydraulic, etc.

Performance @ 25℃ (77℉)

Accuracy*	<±0.25% BFSL typ.
Stability(1 year)	<±0.25% FS typ.
Over range Protection	2X rated Pressure (4X optional)
Burst Pressure	5X or 20,000psi (whichever is less)
Pressure Cycles	>100 Million
Output	0-5V	1-5V	4-20mA	10mV/V**
Excitation	10-28VDC	10-28VDC	10-28VDC	10V EXC as max
Zero Offset	<±0.75%			<±2% of FS
Span Tolerance	<±0.75%			<±2% of FS
Reverse Polarity Protection	Yes
* Accuracy includes: Non-linearity, Hysteresis and Non-repeatability
** 10VDC, Maximun

Environmental Data

Temperature
Media	-40 to 125℃ (-40 to 257℉)
Operating	-40 to 105℃ (-40 to 221℉)
Storage	-40 to 125℃ (-40 to 257℉)
Thermal Limits
Compensated Range	0 to 60℃ (30 to 140℉)
TC Zero	<±1% of FS
TC Span	<±1% of FS
Other
Shock	100G, 11msec, 1/2 sine
Vibration	10G peak, 20 to 2000Hz
EMI/RFI Protection	Yes
Rating	IP66 (Standard)	IP67 (Optional)

Physical Description

Wetted Material	17-4PH, 316L, Hastelloy C276 (Optional)
Electrical Connection	Packard, Din 43650C, M12, Cable.

MODEL NUMBER CONFIGURATION

Not all configurations are available. Our sales team can recommend the closest available configuration based on your requirements. Contact AVERY INSTRUMENT LTD. for configurations not shown.

Ordering Method
For Example:-

AV400A000A4L0C000

ORDERING INFORMATION

Click the button➠ and find the AVERY Model number

DIMENSIONAL DATA

DOWNLOAD DATASHEET

Warranty

🔮 Workmanship - Avery Instrument Limited (AVERY) pressure sensors have a limited one-year warranty to the original purchaser. AVERY will replace or repair, free of charge, any defective sensor. This warranty does not apply to any units that have been modified; misused, neglected or installed where the application exceeds published ratings; the label getting lost, broken,or unrecognizable when return.
Installation/Applications - The purchaser is responsible for media compatibility, functional adequacy, and correct installation of the sensor.
