Submersible Stainless Steel Media Isolated Pressure Sensor

AV901

Benefits

» No Internal O-ring
» Wide Operating Temperature Range
» Ranges up to 100 PSI
» Low Static and Thermal Errors
» Unparalleled Price and Performace
» Compatible with Wide Range of Liquids
» EMI/RFI Protection
» Rugged Design to Survive in Harsh Environments
» High Strength Stainless Steel Construction

Applications

» Ground Water Level Dept Measurement
» Earthened & Concrete Dams
» Gasoline & Diesel Fuel Tanks
» Liquid Level Tanks
» Waste Water Canals
» Vent Tube Filter Available

Overview

AV901 series submersible level sensors offer the best price performance ratio in the industry by utilizing the latest in MEMs piezo-resistive technology using corrosion resistance 316L stainless steel (Hastelloy C276 optional). From 0-1 to 0-100PSI pressure / level measurement, this submersible pressure transducer is an excellent solution to level monitoring for indoor and outdoor applications.

Performance @ 25℃ (77℉)

Accuracy*	<±0.25% BFSL, typ.
Stability(1 year)	<±0.25% of FS, typ.
Pressure Range	100PSI Maximun
Over range Protection	2X Rated Pressure
Burst Pressure	5X or 1,250psi (whichever is less)
Pressure Cycles	>50 million
Output	Volt.	4-20mA	0.5-4.5V	10mV/V**
Excitation	10-28VDC		5VDC typ.
Zero Offset	<±0.5% of FS, typ.			<±2mV
Span Tolerance	<±0.5% of FS, typ.			<±2mV
Reverse Polarity Protection	Yes
* Accuracy includes non-linearity, hysteresis & non-repeatability
** 10VDC, Maximun

Environmental Data

Temperature
Operating	-40 to 85℃ (-40 to 185℉)
Storage	-40 to 100℃ (-40 to 212℉)
Thermal Limits
Compensated Range	0 to 55℃ (30 to 130℉)
TC Zero	<±1% of FS
TC Span	<±1% of FS
Other
Shock	100G, 11msec, 1/2 sine
Vibration	10G peak, 20 to 20000HZ
EMI/RFI Protection	Yes
Rating	IP68

Physical Description

Wetted Material	316L / Hastelloy C276 / Titanium
Weight	200g
Electrical Connection	cable

MODEL NUMBER CONFIGURATION

Not all configurations are available. Our sales team can recommend the closest available configuration based on your requirements. Contact AVERY INSTRUMENT LTD. for configurations not shown.

Ordering Method
For Example:-

AV901B0D1GJH0J000

ORDERING INFORMATION

Click the button➠ and find the AVERY Model number

DIMENSIONAL DATA

DOWNLOAD DATASHEET

Warranty

🔮 Workmanship - Avery Instrument Limited (AVERY) pressure sensors have a limited one-year warranty to the original purchaser. AVERY will replace or repair, free of charge, any defective sensor. This warranty does not apply to any units that have been modified; misused, neglected or installed where the application exceeds published ratings; the label getting lost, broken,or unrecognizable when return.
Installation/Applications - The purchaser is responsible for media compatibility, functional adequacy, and correct installation of the sensor.
